Technical Parameter
| Parameter of safety door switch | ||
| Electromagnetic tube | ||
| Rated Voltage | DC 24V | |
| Capacity | Approximate 4.8W*1 | |
| Rated current | Approximate 200mA*2 | |
| Insulation | Class B (130°C） | |
| LED indicator | ||
| Rated voltage | DC 24V | |
| Rated current | Approximate 1mA | |
| Luminous color (LED) | Green | |
| Safety level | PL d (ISO 13849-1) | |
| Certificate | TÜV Rheinland | |
| Standard | EN60947-5-1、 GB/T 14048.5、 EN ISO 14119、GB/T 18831 | |
| Protection rate | IP67 | |
| Material | PA66 fire retardant | |
| Mechanical lifespan | Over 1,000,000 times | |
| Electrical lifespan | over 150, 000 times | |
| Using Type | AC-15 | DC-13 |
| Rated operating voltage(Ue) | 240V | 24V |
| Rated operating current(Ie) | 3A | 2A |
| Electrical parameter | ||
| Contact resistance | <200mΩ | |
| Nominal discharge current (lth) | 10A | |
| Rated insulation voltage (Ui) | 300V | |
| Anti-electric shock level | Class II (double insulation) | |
| Pulse withstand voltage (EN60947-5-1) | 2.5KV | |
| Insulation resistance | >100mΩ | |
| Short-circuit protection | 10A, 250V requires a quick-break fuse | |
| Vibration resistance | 10-55HZ, double amplitude 1.5mm | |
| Compact resistance | Durability 1000m/s² | |
| Conditional short-circuit current | 100A (EN 60947-5-1) | |
| Space of contact | Above 2 *2mm | |
| Action characteristic | ||
| Direct opening force | Min. 60N | |
| Direct opening travel | Over 10mm | |
| Allowed operating speed | 0.1-0.5m/s | |
| Allowed operating frequency | Maximum 30 times/minute | |
| Holding force | 1300N | |
| Environment | ||
| Operating environment | 3 (EN 60947-5-1) | |
| Operating temperature | -10 ~55°C ( no freezing) | |
| Operating humidity | <95% RH | |
Remark:
1. The maximum power consumption of switch during startup is no more than 15W, after which it will return to below 4.8W.
2. The maximum current draw when start switch not exceed 600mA, after which the current consumption will return to below 200mA.
Product Size
Model selection (eg.: SLM11-APM3)
Contacts action
Option for Brackets
Installation picture
Bracket Name
Brackets Size
Loosen 4 screw on top of head, rotate the head to the right key inserting position and then install it.
When install on slide hung door, it should be over than semidiameter.
Please install the safety switch and insertion key under range 1-3.5mm.
The installation of operation key allows ±1mm deviation within the key insertion center of the hole.
Plastic
Magnetic voltage / indicator | Lock/ Release method | Contact type (door monitor + lock monitor) | Connector size | Model |
Electromagnet DC24V Green LED | Power to release | 1NO+1NC | M16 | SLM11-APM3 |
| 1NC+1NC | M16 | SLM11-CPM3 | ||
Power to lock | 1NO+1NC | M16 | SLM11-APE3 | |
| 1NC+1NC | M16 | SLM11-CPE3 |
Metal
Magnetic voltage / indicator | Lock/ Release method | Contact type (door monitor + lock monitor) | Connector size | Model |
Electromagnet DC24V Green LED | Power to release | 1NO+1NC | M16 | SLM11-AMM3 |
| 1NC+1NC | M16 | SLM11-CMM3 | ||
Power to lock | 1NO+1NC | M16 | SLM11-AME3 | |
| 1NC+1NC | M16 | SLM11-CME3 |
