Specification
| Diameter | Φ53mm | Life-span | 50000 hours |
| Housing | ABS | Lampshade Material | PC |
Working status | Steady | LED source | I color of LEDS |
| Sound source | Buzzer "BBB..." | Dimmable/ Ajustable volume | NO |
| Protection degree | IP20 | Wire connecting | Positive/ Negative |
| Nominal voltage | DC24V | Length of wire | 300±15mm (standard) M12 |
| Rated current | 0.02A @red/ 0.03A@ yellow/ 0.01A @green | ||
Size
Control Circuit Diagram
Trouble Shooting & Precaution
